Description
xProduct Introduction
Metal Substrate DOC Catalyst for Diesel Vehicles
Our metal-based DOC catalysts offer superior durability and faster light-off than traditional ceramic options. With excellent thermal conductivity and vibration resistance, they ensure reliable emission control in demanding diesel applications.
| Product name | Diesel Oxidation Catalyst | Model | DOC Catalyst |
| Euro 5(Euro3/4/5) | Euro 6 | PT/20gr ft³ | |
| Cpsi | 300/400 | Customization | Support |
| Error | ±0.1mm | Quality | High standard |
| Package | Neutral packaging | Price includes |
1 pcs DOC +1 pcs Insulation Materials |
Sellers’ Notes Checklist
Important things |
|
|---|---|
|
1 |
• This product is suitable for highway diesel vehicles with good vehicle condition and normal exhaust temperature. |
|
2 |
• Usually PT/10gr ft³/PT/20gr ft³ corresponds to the original vehicle size of the emission standard, which is enough to achieve the corresponding emission effect. Since ours is a replacement product, not the original, there is a difference in precious metal content with the original DOC. If you mind this situation, don't pay. |
|
3 |
• If you have any requirements for PD, RH, Or there are higher requirements for precious metal content • Please contact us. |
|
4 |
• For non-road equipment, the engine exhaust temperature is relatively low, such as generators/mining equipment, etc. It needs to be judged based on factors such as working environment/power/exhaust temperature, please contact us. |
|
5 |
• We have super stock, PT/5gr ft³/PT/10gr ft³/PT/15gr ft³/PT/20gr ft³/PT/30gr ft³/PT/60gr ft³......Bulk purchase customers please contact us privately to apply for order discounts |
| Product link is the price of a single sample | For bulk purchases, please contact our staff | |
Ready to Upgrade?
👉 Click to Order Now | 📞 Contact Sales:
Product Specifications
| Picture | Description and Specifications |
|---|---|
 |
The Diesel Oxidation Catalyst (DOC) is a device installed inthe engine exhaust line to convert carbon monoxide (CO)and hydrocarbons (HC) in the enginèexhaust into harmlesswater (H20) and carbon dioxide (CO2) through oxidationreactions.
Formula: 2CO+O2--2CO2 CxHy+(x+4y)O2--xCO2+2yH2O |
Metal DOC Catalyst vs. Ceramic: Stronger & Lighter
Metal substrate DOCs outperform ceramic with 3X better shock resistance, 50% faster light-off, and 30% weight reduction. Ideal for tough diesel conditions requiring durability and efficiency.
Fast facts
1.Converts carbon monoxide (CO) into carbon dioxide (CO2) and water
2.Can eliminate muffler requirement
3.Harmful particulates are oxidised into harmless products
What are the strengths of our solution?
Our DOCs provide a simple solution for original equipment manufacturers (OEMs). They’re easy to install and maintain and don’t require any additional control from the machine operator. In many cases, the need for a muffler can be eliminated, and our DOCs can also allow for a wider ratings envelope. Concentrations of NO and NO2 can be optimised in the exhaust stream, and if your engine has SCR, this will make it more efficient and reduce diesel exhaust fluid (DEF) consumption requirements. Using a DOC also enables additional passive regeneration in DPF systems.
Additional Information
xMetal honeycomb, nearly 10,000 specifications, non-standard customization
- Housing:
- 316L, 304, 444, 441 (or customer-specified)
- Core material:
- FeCr21AL6
- Carrier outer diameter:
- 12~960mm
- Height:
- 9~150mm
- Cpsi:
- 5~1200cpsi
- Shell wall thickness:
- 0.5~3.0, no shell is available
- Core wall thickness:
- 0.03~0.18
- Inner core:
- one core, S core, three cores
- Shape:
- cylindrical, rectangular, square, runway-shaped, oval, trapezoidal, pentagonal, pear-shaped
Shipping & Return
xReturns Policy
You may return most new, unopened items within 30 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Shipping
We can ship to virtually any address in the world. Note that there are restrictions on some products, and some products cannot be shipped to international destinations.
When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options you choose. Depending on the shipping provider you choose, shipping date estimates may appear on the shipping quotes page.
Please also note that the shipping rates for many items we sell are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.
About Customization
x| First | Please tell us what you want to do (ceramic or metal catalyst or DPF, DOC, DPF) |
| Second | Please tell us the customized material, coating requirements, CPSI, purchase quantity, etc |
| Third | If it is a custom metal package, a custom drawing is required |
| Fourth | If the catalyst is customized, there are numerical requirements for PD, PT, RH, and the minimum sample is 3 |
| Proin Fifth | If you need to customize the three-way catalyst assembly (the whole exhaust pipe) if we don't have a sample, you need to provide a sample to us |
| Finally | Whatsapp:+8613335696939,Email:KSRCAT@proton.me |
